Standard Dimensional
Tolerance Table - Molded Rubber Products
Drawing Designation "A1"
High Precision |
|
|
| Size |
Millimeters |
|
Closure |
|
Size |
Inches |
Fixed |
Closure |
| Above |
Incl. |
|
|
|
Above |
Incl. |
|
|
| 0 |
10 |
± .10 |
± .13 |
0 |
.40 |
± .004 |
± .005 |
| 10 |
16 |
± .13 |
± .16 |
.40 |
.63 |
± .005 |
± .006 |
| 16 |
25 |
± .16 |
± .20 |
.63 |
1.00 |
± .006 |
± .008 |
| 25 |
40 |
± .20 |
± .25 |
1.00 |
1.60 |
± .008 |
± .010 |
| 40 |
63 |
± .25 |
± .32 |
1.60 |
2.50 |
± .010 |
± .013 |
| 63 |
100 |
± .32 |
± .40 |
2.50 |
4.00 |
± .013 |
± .016 |
| 100 |
160 |
± .40 |
± .50 |
4.00 |
6.30 |
± .016 |
± .020 |
|
| |
|
Standard
Dimensional Tolerance Table - Molded Rubber
Products
Drawing Designation "A2" Precision |
|
|
| Size |
Millimeters |
|
Closure |
|
Size |
Inches |
Fixed |
Closure |
| Above |
Incl. |
|
|
|
Above |
Incl. |
|
|
| 0 |
10 |
± .16 |
± .20 |
0 |
.40 |
± .006 |
± .008 |
| 10 |
16 |
± .20 |
± .25 |
.40 |
.63 |
± .008 |
± .010 |
| 16 |
25 |
± .25 |
± .32 |
.63 |
1.00 |
± .010 |
± .013 |
| 25 |
40 |
± .32 |
± .40 |
1.00 |
1.60 |
± .013 |
± .016 |
| 40 |
63 |
± .40 |
± .50 |
1.60 |
2.50 |
± .016 |
± .020 |
| 63 |
100 |
± .50 |
± .63 |
2.50 |
4.00 |
± .020 |
± .025 |
| 100 |
160 |
± .63 |
± .80 |
4.00 |
6.30 |
± .025 |
± .032 |
| 160 |
&over multiply by |
.004 |
.005 |
6.30 |
&over multiply by |
.004 |
.005 |
|
| |
|
Standard
Dimensional Tolerance Table - Molded Rubber
Products
Drawing Designation "A3" Commercial |
|
|
| Size |
Millimeters |
|
Closure |
|
Size |
Inches |
Fixed |
Closure |
| Above |
Incl. |
|
|
|
Above |
Incl. |
|
|
| 0 |
10 |
± .20 |
± .32 |
0 |
.40 |
± .008 |
± .013 |
| 10 |
16 |
± .25 |
± .40 |
.40 |
.63 |
± .010 |
± .016 |
| 16 |
25 |
± .32 |
± .50 |
.63 |
1.00 |
± .013 |
± .020 |
| 25 |
40 |
± .40 |
± .63 |
1.00 |
1.60 |
± .016 |
± .025 |
| 40 |
63 |
± .50 |
± .80 |
1.60 |
2.50 |
± .020 |
± .032 |
| 63 |
100 |
± .63 |
± 1.00 |
2.50 |
4.00 |
± .025 |
± .040 |
| 100 |
160 |
± .80 |
± 1.25 |
4.00 |
6.30 |
± .032 |
± .050 |
| 160 |
&over multiply by |
.005 |
.008 |
6.30 |
&over multiply by |
.005 |
.008 |
|
| |
|
Standard
Dimensional Tolerance Table - Molded Rubber
Products
Drawing Designation "A4" Basic |
|
|
| Size |
Millimeters |
|
Closure |
|
Size |
Inches |
Fixed |
Closure |
| Above |
Incl. |
|
|
|
Above |
Incl. |
|
|
| 0 |
10 |
± .32 |
± .80 |
0 |
.40 |
± .013 |
± .032 |
| 10 |
16 |
± .40 |
± .90 |
.40 |
.63 |
± .016 |
± .036 |
| 16 |
25 |
± .50 |
± 1.00 |
.63 |
1.00 |
± .020 |
± .040 |
| 25 |
40 |
± .63 |
± 1.12 |
1.00 |
1.60 |
± .025 |
± .045 |
| 40 |
63 |
± .80 |
± 1.25 |
1.60 |
2.50 |
± .032 |
± .050 |
| 63 |
100 |
± 1.00 |
± 1.40 |
2.50 |
4.00 |
± .040 |
± .056 |
| 100 |
160 |
± 1.25 |
± 1.60 |
4.00 |
6.30 |
± .050 |
± .063 |
| 160 |
&over multiply by |
.008 |
.010 |
6.30 |
&over multiply by |
.008 |
.010 |
|
| |
| |
